21° beam angle

Wiring options - EU-model: 208/230/240V AC, 50/60Hz

Wiring options - US model: 100/120/208/230/240V AC,50/60Hz

Power consumption: 300 VA at 230V/50Hz

Height: 415 mm (16.3") - head in horizontal position

Width: 292 mm (11.5")

Depth: 378 mm (14.9")

Weight - EU model: 10.5 kg (23.1 lbs), US model: 12.5 kg (27.6 lbs)

Maximum ambient temperature (Ta): 40°C (104°F)

Maximum surface temperature: 80°C (176°F)

Protocol: USITT DMX-512

Control channels: 8

Bilt-in demo sequences

Display: 4-digit LED display

Pan/Tilt resolution: 8- or 16-bit

Master/slave operating

4 DMX channel-presettings

Movement control: Tracking and vector

Buit-in analyzer for easy fault finding

Data in/out: Locking 3-pin XLR

built-in microphone for audio mode

Colour wheel: 11 dichroic filters + open

Dimmer/Shutter: Full range dimming and variable strobe effect

Pan: 530°

Tilt: 280°

Maximum Pan-movement 530° in 3 s

Maximum Tilt-movement 280° in 1.9 s

via 2 Omega holders
