ROBIN® 300 Plasma Wash

Robe‘s plasma lightsource revolution continues with this latest addition to the generation of ROBIN® fixtures harnessing the power and sustainability of the LIFI ENT 31-02 plasma source.

The ROBIN® 300 Plasma Wash has a perfect colour rendering index of 94, a CCT of 5400 K and an amazing 10.000 hours average lamp life.

The zoom is an impressive 10 – 35 degrees, and onboard effects include smooth, fast colour mixing, including CMY and CTO dichroic colour flag system, plus a colour wheel with 7 replaceable SLOT&LOCK trapezoid shaped dichroics and open position.

It‘s robustly engineered to Robe‘s exacting standards, and applications will include tours, special events and fixed installations of all types.

technical

specification

  • Light Source

    • Lamp: Plasma source
    • Approved model: Lifi ENT 31-02, 266 W, Luminous Flux 18.000 Lm, CCT 5.400 K, CRI=94, lamp life 10.000 Hrs
  • Optical System

    • Hard aluminium reflector
    • Beam angle: 10° –    35°
  • Electrical Specification

    • Power supply: Electronic auto-ranging
    • Input voltage range: 100  –  240 V, 50/60 Hz
    • Power consumption: 400 VA at 230 V/50 Hz
  • Mechanical Specification

    • Height: 595 mm (23.4 ")
    • Width: 438 mm (17.2 ")
    • Depth: 408 mm (16.1 ")
    • Weight: 20.5 kg (45 lbs)
    • Fixation option: Pan/Tilt-lock mechanism
  • Thermal

    • Maximum ambient temperature: 40 °C (104 °F)
    • Maximum surface temperature: 80 °C (176 °F)
  • Control and Programming

    • Setting & Addressing: ROBE Navigation System 2 (RNS2)
    • Protocols: USITT DMX-512, RDM, ArtNet, MA Net, MA Net2
    • Control channels: 14, 16, 19
    • 3 DMX protocol modes
    • 3-editable programs, each up to 100 steps
    • Stand-alone operation
    • Display: QVGA Robe touch screen with battery backup gravitation sensor for auto screen positioning operation memory service log with RTC
    • Pan/Tilt resolution: 8 or 16 bit
    • Movement control: Tracking and vector
    • Colour wheel positioning: 8 or 16 bit
    • Zoom: 8 or 16 bit
    • Dimmer: 8 or 16 bit
    • Ethernet port: ArtNet protocol, ready for ACN
    • Data in/out: Locking 3-pin & 5-pin XLR
    • Built-in analyser for easy fault finding
    • Optional wireless version available: CRMX™ technology from Lumen Radio
  • Electromechanical Effects

    • Cyan: 0 –100%
    • Magenta: 0 –100%
    • Yellow: 0 –100%
    • CTO: 0 –100%
    • Colour wheel: 7 replaceable "SLOT&LOCK" dichroic filters + open, trapezoid shape
    • Dimmer/Shutter: Full range dimming and variable strobe effect
    • Motorized zoom
    • Pan: 540°
    • Tilt: 260°
  • Rigging

    • Mounting points: 2 pairs of ¼-turn locks
    • 2x Omega bracket with ¼-turn quick locks
    • Safety chain/rope attachment point
  • Optional Accessories

    • Front wide-angle lens
    • Top hats
