Striking bright 0° parallel beams with glowing colours and static gobo wheel patterns can be multiplied by innovative Dynamic Flower Effect – DFE™ producing various different shapes of flower beams DFE™ dynamically changing in the air. Fine tuned short arc of the Osram Sirius HRI 140 W RO lamp and optimized optical system pushes with ease through haze and fog. Smooth variable frost filter and any one of the 13 rich colours is instantly ready to create a smooth even wash, extending the feature set of this petite but powerful Beam, Wash and Effect fixture.

Light source

Osram Sirius HRI 140 W RO

Light output

4.960 lm, 400.000 lx @ 5m

Zoom range

3° fixed beam

Effects

static gobo wheel, Dynamic Flower Effect, Beam Shaper

Innovations

Framing shutter emulation

Robe's innovative framing shutter emulation delivers a variety of beam shaping forms, usually only achievable with framing shutters and beam shapers.

MLP™ - Multi-level prisms

The patented prism effects engine can overlay two levels of prisms and produce a wide array of varying beam and ‘flower’ effects, further creating a whole new collection of eye-popping creativity.

GDTF – General Device Type Format

The General Device Type Format creates a unified definition for exchange of data for the operation of intelligent luminaries, such as moving lights. The file format is human readable and developed using open source formats.

Product Video

Technical Specification

Expand AllDownload PDFCollapse All

Source

Lamp: Discharge short arc lamp with integrated reflector

Approved model: Osram Sirius HRI 140 W RO

Life time : 6.000 hours

CRI: 65

CCT: 8000 K

Control: Automatic and remote on/off

Ballast: Electronic

Optical system

Dynamic Effects and Features

Colour wheel: 13 dichroic filters + white

Static Gobo wheel: 10 gobos + 3 beam reducers

DFE™ – Dynamic Flower Effect – creating spectacular beam effects in the air which can change shape, size and speed of rotation (patent pending)

Beam Shaper: Variable shape, indexable and rotatable

Frost effect: Separate, variable

Motorized focus

Pre-programmed random strobe & pulse effects

Dimmer: smooth dimming

Control and programming

Setting & Addressing: two-row LCD display & 4 control buttons

Wireless CRMX™ technology from Lumen Radio: On request

DMX Protocol modes: 3

Control channels: 22, 17, 27

Stand-alone operation

3-editable programs, each up to 40 steps

Pan/Tilt resolution: 16 bit

Colour wheel positioning: 8 or 16 bit

Static gobo wheel positioning: 8 bit

Prism indexing & rotation: 8 bit

Frost: 8 bit

Focus: 8 or 16 bit

Dimmer: 8 or 16 bit

Movement

Static gobos

Thermal specification

Electrical specification and connections

Approvals

Mechanical specification

Rigging

Included items

Optional accessories

Lamp Osram Sirius HRI 140W RO: 14080051

Wireless DMX external module: 10980127

Mounting adapter for one omega holder: 10980100

Doughty Trigger Clamp: 17030386

Mains Cable powerCON In/Schuko 2m: 13051724

Mains Cable powerCON In/CEE 16A 2m: 13051725

Mains Cable powerCON In/US 2m: 13051726

Mains Cable powerCON In/open ended 2m: 13051731

Daisy Chain powerCON In/Out EU 2m: 13051727

Daisy Chain powerCON In/Out US 2m: 13051728

Single Top Loader Case: 10120168-01

Quad Top Loader Case: 10120169-01

Foam Shell: 20020225
