Light output: Comparable with 2500 ANSI lumen lamp projectors

Aspect ratio: 16:10

Resolution: WXGA (1280x800)

Beam angle: 16°

Throw ratio: 3.5:1

Contrast ratio: 700:1

Display colours: 16.7 million colours

Colour mixing mode RGB/CMY

Colour effect wheel with wide range of in-built effects (colour transitionsand cross-fades, multiple colour images, rainbow effects)

Upload and projection of custom artwork, still photographs and videos from USB memory stick

Digital gobo wheel with gobos, images and videos

Gobo rotation and indexing

Video speed control

Live input via external High Defenition Multimedia Interface

Effect wheel with wide range of graphic effects (Kaleidoscopic effect, fish eye, iris, zoom, swirl effect, pixelation effect, cross-stitching, posterization, and more,…)

Effect speed control

Horizontal/Vertical keystoning

Iris: Digital

Motorized focus

Pre-programmed random strobe & pulse effects

Dimmer: 0 - 100%

Setting & Addressing: two-row LCD display & 4 control buttons

Protocols: USITT DMX-512, RDM, ArtNet, sACN

Wireless CRMX™ technology from Lumen Radio (on request): On request

DMX Protocol modes: 1

Control channels: 24

Stand-alone operation

Pan movement: 450°

Tilt movement: 270°

Controllable speed of Pan/Tilt movement

Rapsberry Pi Model B 512 MB RAM

Linux OS

Maximum ambient temperature: 40°C (104°F)

Maximum surface temperature: 60°C (140°F)

Minimum operating temperature: 0°C (32°F)

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: 90 W at 230 V / 50Hz

Power in/out connector: Neutrik powerCON in/out

DMX and RDM data in/out: Locking 3-pin & 5-pin XLR

Ethernet port in/out: RJ45

2x USB 2.0 connector (series A)

External video input 1x High Definition Multimedia Interface (HDMI)

CE Compliant

cETLus Compliant

Height: 343 mm (13.5")

Width: 290 mm (11.41")

Depth: 295 mm (11.61")

Weight: 6.4 kg (14.1 lbs)

Mounting points: 1 pair of ¼-turn locks

1x Omega adaptor with ¼-turn quick locks

Universal operating position

Safety cable attachment point

User Manual

Omega Adaptor CL-regular

Power cord including powerCON In connector

Wireless DMX external module incl. rear base cover for MiniMe DV: 10980368

Wide angle lens for MiniMe DV: 10980369

Doughty Trigger Clamp: 17030386

Safety wire 35 kg: 99011963

Mains Cable powerCON In/Schuko 2m: 13051724

Mains Cable powerCON In/CEE 16A 2m: 13051725

Mains Cable powerCON In/US 2m: 13051726

Mains Cable powerCON In/open ended 2m: 13051731

Daisy Chain powerCON In/Out EU 2m: 13051727

Daisy Chain powerCON In/Out US 2m: 13051728

MiniMe DV® is a Registered Trademark of Robe lighting s. r. o.

MiniMe DV® is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents
