Source

Lamp: Compact high-pressure metal halide lamp

Base: GY-9.5

Approved model: Philips MSD 250W/2

Control: Automatic and remote on/off

Ballast: Magnetic

Optical system

Multi-step zoom (15°, 18°, 21°, 24°, 26°)

Electrical specification and connections

Wiring options - EU-model: 208/230/240V AC, 50/60Hz

Wiring options - US model: 100/120/208/230/240V AC,50/60Hz

Power consumption: 500 VA at 230V/50Hz

Mechanical specification

Height: 476 mm (18.7") - head in horizontal position

Width: 428 mm (16.9")

Depth: 380 mm (15.0")

Weight - EU model: 20.5 kg (45.2 lbs), US model: 23.5kg (51.8 lbs)

Thermal specification

Maximum ambient temperature (Ta): 45°C (113°F)

Maximum surface temperature: 80°C (176°F)

Rotating gobos

Outside diameter - metal gobos: 37.3 mm, glass gobos: 37.2 mm

Thickness - metal gobos: 0.15mm (steinless steel); glass gobos: Max. thickness = 4mm (high temperature borofloat or better glass)

Control and programming

Protocol: USITT DMX-512

Control channels: 16

Bilt-in demo sequences

Display: 4-digit LED display

Pan/Tilt resolution: 8- or 16-bit

Master/slave operating

Controllable speed of fans

Movement control: Tracking and vector

Buit-in analyzer for easy fault finding

Data in/out: Locking 3-pin XLR

Electromechanical effects

Colour wheel: 7 dichroic filters + open

Colour/Gobo wheel: 3 dichroic filters, 3 dichroic gobos + open

Rotating gobo wheel: 5 rotating, indexable, replaceable gobos + open

Prism: 3-facet -prism rotating in both directions at different speeds

Dimmer/Shutter: Full range dimming and variable strobe effect

Focus: motorized focus

Pan: 530°

Tilt: 280°

Maximum Pan-movement 530° in 2.7 s

Maximum Tilt-movement 280° in 1.7 s

Rigging

via 2 pairs of mounting holes for clamps with M10 thread

via mounting bracket

Optional accessories

Mounting bracket with screws
