ParFect 150™ FW RGBA

The ParFect 150 FW RGBA has a bright, Fresnel style soft-beam edge, with zoom control and a high CRI in an economical LED format.

Light source

7x 40W RGBA multichips

Light output

1.796 lm, 7.610 lux @ 5 m

Zoom range

3,8° – 60°

| ROBE lighting

It produces warm golden tones while retaining the key features of precise colour control via CMY or RGBA colour mixing, ultra-smooth 18-bit dimming and a powerful 3,8° to 60° zoom.

This compact, lightweight fixture includes a combined hanging/floor stand bracket, accessories such as barn doors and the gel frame, making it a versatile fixture for theatrical and educational applications.

Parfect 150™ FW RGBA is now equipped with Robe's innovative lens coating technology which brings benefits such as bright and clear lenses, no scratches or marks, higher light output and longer intervals between cleaning.

Technical Specification

Source

Light source type: 7x 40W RGBA multichips

LED life expectancy: min. 50.000 hours

Typical lumen maintenance: L70/B50 @ 50.000 hours

Optical system

Robe’s proprietary optical design

High - efficiency zoom optical system, ratio 15,5:1

Zoom range: 3.8° - 60°

Diffusion filter imbedded

Fixture total lumen output: 1.796 lm

Illuminance: 7.610 lx @ 5 m

Innovative lens coating technology (Patent pending)

Dynamic Effects and Features

Colour mixing mode RGBA or CMY

Variable CTO: 2.700K - 8.000K

Virtual Colour Wheel: with 66 preset swatches

Tungsten lamp effect at whites: 2.700K and 3.200K (red shift and thermal delay)

Motorized zoom

Pre-programmed random strobe & pulse effects

High resolution electronic dimming: 0 - 100%

Control and programming

Setting & Addressing: two-row LCD display & 4 control buttons, stand-alone operation with 3 editable programs (each up to 25 steps)

Protocols: USITT DMX-512, RDM

Wireless CRMX™ technology from Lumen Radio - on request

DMX Protocol modes: 2

Control channels: 17, 11

RGBA / CMY: 8 or 16 bit

Zoom: 8 or 16 bit

Dimmer: 8 or 16 bit (internal 18 bit)

Thermal specification

Maximum ambient temperature: 40°C (104°F)

Maximum surface temperature: 80°C (176°F)

Minimum operating temperature: -5°C (23°F)

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: Max. 220 W

Power in/out connector: Neutrik powerCON in/out

DMX and RDM data in/out: Locking 5-pin XLR

Approvals

CE Compliant

cETLus Compliant

Mechanical specification

Height: 192 mm (7.6")

Width: 240 mm (9.45")

Depth: 392 mm (15.43") without hanging bracket / 498 mm (19.6") with hanging bracket

Weight: 5 kg (11 lbs)

Ingress protection rating: IP20

Rigging

Mounting horizontally or vertically via mounting yoke

Universal operating position

Safety cable attachment point

Included items

Accesory frame adaptor

User Manual

Optional accessories

Wireless DMX external module: 10980127

Gel frame: 10980372

Clear lens cover: 10980604

Barndoor module: 10980349

EggCrate: 10980346

HALO frame adaptor: 10980348

Doughty Trigger Clamp: 17030386

Safety wire 36 kg: 99011963

Mains Cable powerCON In/Schuko 2m: 13051724

Mains Cable powerCON In/CEE 16A 2m: 13051725

Mains Cable powerCON In/US 2m: 13051726

Mains Cable powerCON In/open ended 2m: 13051731

Daisy Chain powerCON In/Out EU 2m: 13051727

Daisy Chain powerCON In/Out US 2m: 13051728

Single Top Loader Case: 10120217-02

Six Pack Top Loader Case: 10120218-02

Eight Pack Top Loader Case: 10120219-02

Dual Foam Shell: 20020301-01

Legal

ParFect 150™ is a trademark of Robe lighting s. r. o.

ParFect 150™ FW RGBA is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents
