Bigger, brighter and bolder, the SuperSpikie takes the look to another level.

Light source


Light output

5.105 lm

Zoom range



MCFE™ - Multi-Coloured Flower Effects (patented), Colour Rainbow Effect, 3 Facet Prism, Rotating gobo wheel

| ROBE lighting

Four times brighter than the original Spikie and with the addition of rotating gobos – this effects machine has even more looks to blast through its 165mm lens front.

The Zoom is bigger too. From a 3,5° beam to a soft wash at 42°, the CMY or RGBW colour mix looks rich. In-air effects using different combinations of the gobos, prism or Robe patented MCFE™ - Multi-Coloured Flower Effects, make this a versatile stage, set or studio piece. With the ability to mount it in any position, the fast 360° continuous pan and tilt motors add yet another dimension.

Technical Specification


Light source type: 250W RGBW LED multichip

LED life expectancy: min. 20 000 hours

Typical lumen maintenance: 70% @ 20 000 hours

Optical system

Robe’s proprietary optical design

High - efficiency zoom optical system, ratio 12:1

Zoom range:

  • 3.5°- 35° Beam mode

  • 5° - 42° Wash mode

Output lens diameter: 165 mm

Fixture total lumen output:

  • 5.105 lm (integrating sphere)

  • 4.100 lm (goniophotometer)

Dynamic Effects and Features

Colour mixing mode RGBW or CMY

Variable CTO: 2.700K - 8.000K

Virtual Colour Wheel: with 66 preset swatches

Tungsten lamp effect at whites: 2.700 K and 3.200 K (red shift and thermal delay)

Colour rainbow effect with variable speed

Rotating gobos: 2 rotating, indexable and replaceable, specifically designed for mid-air effects

MCFE™ - Multi-Coloured Flower Effects – creating spectacular multicolour beam effects in the air rotating in both directions at variable speed (patented)

Prism 1: 3-facet circular prism rotating in both directions at variable speeds

Frost: 20°

Motorized zoom

Shutter: Electronic with variable speed strobe (max.20 flashes per second)

Pre-programmed random strobe & pulse effects

High resolution electronic dimming: 0 - 100%

Control and programming

Setting & Addressing: ROBE Navigation System 2 (RNS2)

Display: QVGA Robe touch screen with battery backup, gravitation sensor for auto screen positioning, operation memory service log with RTC, stand-alone operation with 3 editable programs (each up to 100 steps), built-in analyser for easy fault finding

Protocols: USITT DMX-512, RDM, Art-Net, MA Net, MA Net2, sACN, Kling-Net

Wireless CRMX™ technology from Lumen Radio - on request

DMX Protocol modes: 1

Control channels: 31

Pan/Tilt resolution: 16 bit

RGBW / CMY: 8 or 16 bit

Frost: 8 bit

Zoom: 8 or 16 bit

Dimmer: 8 or 16 bit (internal 18 bit)


Pan movement range 540° with continuous rotation control

Tilt movement range 360° with continuous rotation control

Controllable speed of Pan/Tilt movement

Automatic Pan/Tilt position correction

Rotating gobos

2x rotating glass gobos

Image diameter: 22.5 mm

Outside diameter: 26.8 mm

Thickness: 1.1 mm

Max. thickness: 3.5 mm

Thermal specification

Maximum ambient temperature: 45 °C (113°F)

Maximum surface temperature: 70 °C (167 °F)

Minimum operating temperature: -5°C (23°F)

Electrical specification and connections

Power supply: Electronic auto-ranging

Input voltage range: 100-240 V, 50/60 Hz

Power consumption: Max. 330 W at 230 V / 50 Hz

Power in/out connector: Neutrik powerCON TRUE1 in/out

DMX and RDM data in/out: Locking 3-pin & 5-pin XLR

Ethernet port in: RJ45


CE Compliant

cETLus Compliant

Mechanical specification

Height: 670 mm (26.4")

Width: 399 mm (15.7")

Depth: 250 mm (9.8")

Weight: 19 kg (41.9 lbs)

Ingress protection rating: IP20


Mounting positions: Horizontally or vertically

Universal operating position

Mounting points: 2 pairs of 1/4-turn locking points

2x Omega adaptors with 1/4-turn quick locks

Safety cable attachment point

Included items

User Manual

Omega Adaptor CL-regular: 2 pcs

Optional accessories

Doughty Trigger Clamp: 17030386

Safety wire 36 kg: 99011963

Line cords powerCON TRUE1 In:

  • Mains Cable powerCON TRUE1 In/Schuko, 2m, Indoor 13052405

  • Mains Cable powerCON TRUE1 In/US, 2m, Indoor 13052406

  • Mains Cable powerCON TRUE1 In/CEE 16A, 2m, Indoor 13052445

  • Mains Cable powerCON TRUE1 In/open ended, 2m, Indoor 13052407

Line cords powerCON TRUE1 In/Out:

  • Daisy Chain powerCON TRUE1 In/Out, EU, 2m, Indoor 13052439

  • Daisy Chain powerCON TRUE1 In/Out, US, 2m, Indoor 13052440

  • Daisy Chain powerCON TRUE1 In/Out, EU, 5m, Indoor 13052444

Single Top Loader Case: 10120246

Dual Top Loader Case: 10120247-01

Quad Top Loader Case: 10120248-01

Foam Shell: 20020341


SuperSpikie™ is a registered trademark of Robe lighting s. r. o.

SuperSpikie™ is patented by Robe lighting s. r. o. and is protected by one or more pending or issued patents


Rotating Gobo Wheel
