Source

Lamp: Compact high-pressure metal halide lamp

Base: GY9.5

Approved model: Philips MSD 250/2

Control: Automatic and remote on/off

Ballast: Magnetic

Optical system

High luminous-efficiency parabolic reflector

Front fresnel lens of diameter 158 mm

Electrical specification and connections

Wiring options: EU model - 208/230/240 V, 50/60 Hz, US model - 100/120/208/230 V, 50/60 Hz

Power consumption: 405 VA at 230 V/50 Hz

Mechanical specification

Height: 502 mm (19.8 ")

Width: 419 mm (16.5 ")

Depth: 438 mm (17.2 ")

Weight: EU model - 20.5 kg (45.2 lbs), US model - 23.5 kg (51.8 lbs)

Thermal specification

Maximum ambient temperature: 45 °C (113 °F)

Maximum surface temperature: 70 °C (158 °F)

Control and programming

Protocol: USITT DMX-512, RDM support

Control channels: 16, 18 or 20

DMX channels: 4 protocol modes

Built-in demo sequences

Display: 4-digit LED display

Pan/Tilt resolution: 16bit

Colour wheel positioning: 8 or 16bit

Dimmer: 8 or 16 bit

Master/Slave operation

Stand-alone operation

3-editable programs, each up to 99 steps

Movement control: Tracking and vector

Built-in analyzer for easy fault finding

Data in/out: Locking 3-pin XLR & 5-pin XLR

Electromechanical effects

Cyan: 0-100%

Magenta: 0-100%

Yellow: 0-100%

Colour wheel: 6 replaceable ″SLOT&LOCK″ dichroic filters + open

Effect wheel: Beam Shaper rotated by 90°, Frost Filter

Dimmer/Shutter: Full range dimming and variable strobe effect

Zoom: Motorized zoom 8° - 32°

Pan: 530°

Tilt: 268°

Rigging

Mounting points: 4 pairs of ¼-turn locks

2x Omega brackets with ¼-turn quick locks
