Source

Lamp: Compact high-ressure metal halide lamp

Base: GX9.5

Approved model: Philips MSR 575/2

Control: Automatic and remote on/off

Ballast: Magnetic

Optical system

High luminous-efficiency glass reflector

Fresnel lenses of diameter 200 mm

Internal difusion lens of diameter 136 mm

Electrical specification and connections

Wiring options: EU model - 208/230/240V, 50/60Hz, US model - 100/120/208/230V, 50/60Hz

Power consumption: 720VA at 230V/50Hz

Mechanical specification

Height: 588 mm (23.1″) - head in horizontal position

Width: 470 mm (18.5″)

Depth: 446 mm (17.6″)

Weight: EU model - 31 kg (68.3 lbs), US model - 34.5 kg (76.1 lbs)

Thermal specification

Maximum ambient temperature (Ta): 40°C (104°F)

Maximum surface temperature: 80°C (176°F)

Control and programming

Protocol: USITT DMX-512, RDM support

Control channels: 16, 18, 19, 21

DMX channels: 4 protocol modes

Master/Slave operation

Stand-alone operation

3-editable programs, each up to 99 steps

Built-in demo sequences

Display: 4-digit LED display

Pan/Tilt resolution: 16bit

Colour wheel positioning: 8 or 16bit

Zoom: 8 or 16bit

Dimmer: 8 or 16bit

Movement control: Tracking and vector

Built-in analyzer for easy fault finding

Data in/out: Locking 3-pin & 5-pin XLR

Electromechanical effects

Cyan: 0 - 100%

Magenta: 0 - 100%

Yellow: 0 - 100%

CTO: 0 - 100%

Colour wheel: 5 replaceable ″SLOT&LOCK″ colours + open

Dimmer/Shutter: Full range dimming and variable strobe effect

Zoom: 8° - 50°

Pan: 530°

Tilt: 28°

Rigging

Mounting points: 4 pairs of ¼-turn locks

2x Omega bracket with ¼-turn quick locks

Optional accessories

Module of front wide-angle lens D200 (87° angle)

Remote Control IR

Top Hats
