ColorSpot 700E AT™

The ColorSpot 700E AT marks a new series of Robe 700 W movinghead fixtures. Featuring the MSR GOLD 700 FastFit lamp, it is ideal for all professional applications and installations. It also offers a full CMY and CTO colour mixing systems, a colour wheel with 7 replaceable ″SLOT&LOCK″ dichroic filters; a static gobo wheel with 9 replaceable ″SLOT&LOCK″ gobos and a rotating gobo wheel with 7 replaceable ″SLOT&LOCK″ gobos; a replaceable animation wheel and a rotating 3-facet prism. The zoom range is 15° - 51° and there’s also dimmer, shutter, strobe effects.

technical

specification

  • Source

    • Lamp: Compact high-presure metal halide lamp
    • Base: PGJX50
    • Approved model: Philips MSR Gold 700 FastFit
    • Control: Automatic and remote on/off
    • Ballast: Electronic
  • Optical System

    • Dichroic glass reflector for maximising the light efficiency
    • Beam angle: 15° - 51°
  • Electrical Specification

    • Power supply: Electronic auto-ranging
    • Input voltage range: 100-240 V, 50/60 Hz
    • Power consumption: 930 VA at 230 V/50 Hz
  • Mechanical Specification

    • Height: 597 mm (23.5 ") - head in horizontal position
    • Width: 514 mm (20.2 ")
    • Depth: 499 mm (19.7 ")
    • Weight: 32 kg (70.6 lbs)
    • Fixation option: Pan/Tilt-lock mechanism
  • Thermal

    • Maximum ambient temperature: 40 °C (104 °F)
    • Maximum surface temperature: 120 °C (248 °F)
  • Static Gobos

    • Metal gobos - outside diameter: 26.9 mm, image diameter: 22.5 mm, aluminium, thickness: 0.5 mm
  • Rotating Gobos

    • Glass gobos - outside diameter: 26.8 mm, image diameter: 22.0 mm, thickness: 1.1 mm, max. thickness: 4.0 mm, high temperature borofloat or better glass
  • Control and Programming

    • Setting & Addressing: ROBE Navigation System (RNS)
    • Protocol: USITT DMX-512, RDM support
    • Control channels: 26, 28, 31, 34 or 36
    • 5 DMX protocol modes
    • 3-editable programs, each up to 99 steps
    • Stand-alone operation
    • Display: Blue/white LCD graphic
    • Pan/Tilt resolution: 16bit
    • Movement control: Tracking and vector
    • Colour wheel positioning: 8 or 16bit
    • Static gobo wheel positioning: 8 or 16bit
    • Rotating gobos: 8 or 16bit
    • Iris: 8 or 16bit
    • Frost: 8 or 16bit
    • Zoom: 8 or 16bit
    • Dimmer: 8 or 16bit
    • Ethernet port: Art-Net protocol, ready for ACN
    • Data in/out: Locking 3-pin & 5-pin XLR
    • Built-in analyser for easy fault finding
  • Electromechanical Effects

    • Cyan: 0-100%
    • Magenta: 0-100%
    • Yellow:0-100%
    • CTO: 0-100%
    • Colour wheel: 7 replaceable ″SLOT&LOCK″ dichroic filters + open
    • Static Gobo wheel: 9 replaceable ″SLOT&LOCK″ gobos + open
    • Rotating Gobo wheel: 7 rotating, indexable, replaceable ″SLOT&LOCK″ glass gobos + open
    • Animation wheel: Replaceable, variable rotation angle,continuous rotation in both directions at different speeds
    • Iris: Motorized, stepless
    • Prism: 3-facet indexable prism rotating in both directions at different speeds
    • Frost effect: Separate, variable
    • Dimmer/Shutter: Full range dimming and variable strobe effect, Electronic strobbing “ZAP”
    • Motorized zoom and focus
    • Pan: 540°
    • Tilt: 280°
  • Rigging

    • Mounting points: 4 pairs of ¼-turn locks
    • 2 x Omega bracket with ¼-turn quick locks
    • Safety chain/rope attachment point
  • Optional Accessories

    • Remote Control IR
    • Animation Wheels
