ColorSpot 1200E AT Profile™

ColorSpot 1200E AT Profile™

The inbuilt framing shutters enable the fixture to be used like any standard profile discharge lightsource, when very precise framing and pin-pointing of objects and areas onstage is required. This will be of great interest for theatical applications and TV productions.

For full flexibility, the framing shutter module uses 4 rotating blades, and the final framed image can also be rotated.

All other features and functions are similar to the standard ColorSpot 1200E ATTM, with 1 x rotating gobo wheel, 1 x frost effect and iris, 1 x colour wheel and variable CMY and CTO.

technical

specification

  • Source

    • Lamp: Compact high-presure metal halide lamp
    • Base: GY22
    • Approved model: Philips MSR 1200 SA
    • Control: Automatic and remote on/off
    • Ballast: Electronic
  • Optical System

    • Dichroic glass reflector for maximising the light efficiency
    • Beam angle: 12.5° – 37°
  • Electrical Specification

    • Wiring options: 100/120/208/230/250 V, 50/60 Hz
    • Power consumption: 1550 VA at 230 V/50 Hz
  • Mechanical Specification

    • Height: 619 mm (24.4 ") – head in horizontal position
    • Width: 536 mm (21.1 ")
    • Depth: 616 mm (24.3 ")
    • Weight: 43.8 kg (96.6 lbs)
    • Fixation option: Pan/Tilt-lock mechanism
  • Thermal

    • Maximum ambient temperature: 40 °C (104 °F)
    • Maximum surface temperature: 135 °C (176 °F)
  • Rotating Gobos

    • Dichroic glass gobos - outside diameter: 37.3 mm, image diameter: 31.5 mm, thickness: 1.1 mm, max. thickness: 5 mm, high temperature borofloat or better glass, coating: dichroic or enhanced aluminium
  • Control and Programming

    • Setting & Addressing: Blue/white LCD graphic display and RNS (ROBE Navigation System)
    • Protocols: USITT DMX-512, RDM, ArtNet
    • Control channels: 29, 35
    • 2 DMX protocol modes
    • 3-editable programs, each up to 99 steps
    • Stand-alone operation
    • Pan/Tilt resolution: 16 bit
    • Movement control: Tracking and vector
    • Colour wheel positioning: 8 bit
    • Rotating gobos: 8 or 16 bit
    • Frost effect: 8 bit
    • Iris: 8 bit
    • Focus: 8 bit
    • Zoom: 8 bit
    • Framing shutters system: 8 bit
    • Dimmer: 8 or 16 bit
    • Built-in analyser for easy fault finding
    • Ethernet port: Art-Net protocol, ready for ACN
    • Data in/out: Locking 3-pin & 5-pin XLR
  • Electromechanical Effects

    • Cyan: 0–100%
    • Magenta: 0–100%
    • Yellow:0–100%
    • CTO: 0–100%
    • Colour wheel: 6 replaceable "SLOT&LOCK" dichroic filters + open, trapezoid shape
    • Rotating Gobo wheel : 6 rotating, indexable, replaceable "SLOT&LOCK" glass gobos + open
    • Iris: Motorized, stepless
    • Variable frost effect
    • Dimmer/Shutter: Full range dimming and variable strobe effect, Electronic strobbing "ZAP"
    • Motorized zoom and focus
    • Framing shutters system
    • Pan: 540°
    • Tilt: 280°
  • Rigging

    • Mounting points: 4 pairs of ¼-turn locks
    • 2 x Omega bracket with ¼-turn quick locks
    • Safety chain/rope attachment point
