ParFect 100™

The ParFect, an LED source ACL beam at an affordable price and made in Europe.

This unit is a static version of the successful LedBeam 100 and retains all the key features including both CMY & RGBW colour control, Tungsten emulation, Zone Fx, selectable & variable colour temperatures and the really powerful punchy 7° beam. The compact and lightweight moulded composite unit is complete with a combined hanging bracket/floor stand. Wireless DMX, clip-on diffusion filters and detachable barn-doors, are available as additional cost options.

  • Light source

    12x 15W RGBW multichips

  • Light output

    5.960 lux @ 5 m / 3.620 lm

  • Zoom range

  • Effects

    3 LED zones, virtual colour wheel, strobe effects

technical

specification

  • Source

    • Light Source Type: 12x 15W RGBW LED multichips
    • LED Life Expectancy: minimum 60.000 hours
    • Typical Lumen Maintenance: 70 % @ 60.000 hours
  • Optical System & Effects

    • Beam Angle: 7°
    • Colour Mixing System: RGBW or CMY colour mixing, CTO
    • Virtual Colour Wheel: with 237 colours including whites (2.700 K, 3.200 K, 4.200 K, 5.600 K and 8.000 K)
    • LED Zones: 3; individual colour control of each LED zone
    • Tungsten Lamp Effects at Whites: 2700 K and 3200 K
    • High Resolution Dimmer: 0-100%
    • Strobe effect with variable speed (max. 20 flashes per second)
    • Individual zone strobe effects with variable speed
    • Preprogramed random strobe & pulse effects
  • Control and Programming

    • Setting & Addressing: 2-row LCD display & 4 buttons
    • Protocols: USITT DMX 512, RDM
    • Wireless: Optional wireless external module available: CRMX™ technology from Lumen Radio
    • Control Channels: 14, 9, 4, 30, 35, 4
    • Protocol Modes: 6
    • Stand alone operation
    • Data in/out: Locking 5-pin XLR
  • Programs

    • 3 user-editable programs each up to 40 steps
    • 7 built-in programs each up to 40 steps
  • Thermal Specification

    • Maximum Ambient Temperature: 40° C (104° F)
    • Maximum Housing Temperature: 80° C (176°C)
  • Electrical Specification

    • Input Voltage: supply 100-240V, 50-60Hz
    • Power Consumption: max. 200W
    • Power Connector: Neutrik PowerCon In/Out

  • Mechanical Specification

    • Length: 343 mm (13.5") without hanging bracket
    • Height: 173 mm (6.8")
    • Width: 240 mm (9.5")
    • Weight: 4 kg (8.8 lbs)
  • Rigging

    • Mounting Points: Mounting horizontally or vertically via mounting yoke (360° tilt range)
  • Accessories

    • Optional: diffusion filters 40°, 20° and 10°, wireless DMX module, Barndoor module, accesory frame adaptor and gel frame
